Transform to smarter TV connectivity

Use the LAN adapter to wirelessly access content for your Smart TV from the internet or from your digital camera, mobile phone, Note PC or other DLNA-certified multimedia devices. It communicates with your Smart Hub and links instantly with all elements of your Samsung home-entertainment system, giving you complete and easy control. Supported by the latest wireless LAN protocols - 802.11n, 802.11a, 802.11b and 802.11g, as well as DLNA 1.5 – easily access and connect to Samsung’s AllShare™ and directly stream content from devices to your TV.

Enjoy a greater wireless connection

Expand your wireless range and signal by connecting the dongle to your Smart TV. The Samsung wireless dongle is the easiest way to connect to not only the internet but also your DLNA-certified multimedia devices. It keeps your home entertainment system connected with simple controls and doesn’t require other software. And to increase the wireless range and strengthen the signal, connect the dongle to the Smart TV with the included extension cable. Make the jump to easier connectivity that gives you more.

Wireless LAN Adapter (Smart TV)

Yes

IEEE 82.11a/b/g/n

USB 2.0

Host Interface

2.412 ~ 2.4835 GHz / 5.15 ~ 5.85 GHz

Frequency Range

64 / 128 bit WEP, WPA / WPA2, 802 1x, WPS

Security

SHOW MORE SPECS

Standard

IEEE 82.11a/b/g/n

Yes

Host Interface

USB 2.0

Frequency Range

2.412 ~ 2.4835 GHz / 5.15 ~ 5.85 GHz

Security

Security

64 / 128 bit WEP, WPA / WPA2, 802 1x, WPS

Output Power

IEEE 82.11a

16 dBm
IEEE 82.11b

16 dBm
IEEE 82.11g

14 dBm
IEEE 82.11n (2.4GHz)

15 dBm (20 MHz) / 15 dBm (40 MHz)
IEEE 82.11n (5GHz)

17 dBm (20 MHz) / 17 dBm (40 MHz)

Data Rate

IEEE 82.11a/g

54, 48, 36, 24, 18, 12, 9 and 6 Mbps
IEEE 82.11b

11, 5.5, 2 and 1 Mbps
IEEE 82.11n

up to 300 Mbps (40 MHz / spatial streams: 2)

Sensitivity

IEEE 82.11a/g

- 68 dBm at 54 Mbps
IEEE 82.11b

- 84 dBm at 11 Mbps
IEEE 82.11n

- 68 dBm (20 MHz) / - 65 dBm (40 MHz)

Power Consumption

TX (Transmitter)

500 mA
RX (Receiver)

300 mA

Ideal For Streaming HD Video

IEEE 82.11a/b/g/n(2.4GHz)

Not Recommended
IEEE 82.11n (5GHz)

Recommended

Ideal For Streaming SD Video

IEEE 82.11a/b/g/n

Recommended

Compatibility

LED TV

2014 Europe / Türkiye: H5303, H5203

Dimension

Set (WxHxD)

26.6 x 84 x 16 mm
Package (WxHxD)

165 x 95 x 30 mm

Weight

Package

3.85 g
Set

20.4 g

Accessory

AV Gender

Yes
User Manual

Yes
USB Extension Cable

Yes
